Product Summary
The OPA356AIDBVR is a high-speed, voltage-feedback CMOS operational amplifier. It is designed for video and other applications requiring wide bandwidth. The OPA356AIDBVR is unity gain stable and can drive large output currents. Differential gain is 0.02% and differential phase is 0.05°. Quiescent current is only 8.3mA per channel. The applications of the OPA356AIDBVR include video processing, ultrasound, optical networking, tunable lasers, photodiode transimpedance amps, active filters, high-speed integrators.
Parametrics
OPA356AIDBVR absolute maximum ratings: (1)Supply Voltage, V+ to V–: 7.5V; (2)Signal Input Terminals, Voltage: (V–) – 0.5V to (V+) + 0.5V, Current: 10mA; (3)Output Short-Circuit: Continuous; (4)Operating Temperature: –55℃ to +150℃; (5)Storage Temperature: –65℃ to +150℃; (6)Junction Temperature: +160℃; (7)Lead Temperature (soldering, 10s): +300℃.
Features
OPA356AIDBVR features: (1)unity-gain bandwidth: 450MHz; (2)wide bandwidth: 200MHz GBW; (3)high slew rate: 360V/μs; (4)low noise: 5.8nV/√Hz; (5)excellent video performance: diff gain: 0.02%, diff phase: 0.05° 0.1dB gain flatness: 75MHz; (6)input range includes ground; (7)rail-to-rail output (within 100mV); (8)low input bias current: 3pA; (9)thermal shutdown; (10)single-supply operating range: 2.5V to 5.5V.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 OPA356AIDBVR |
Texas Instruments |
High Speed Operational Amplifiers 2.5V 200MHz GBW CMOS Single Op Amp |
Data Sheet |
|
|
||||||||||||
|
OPA356AIDBVRG4 |
Texas Instruments |
High Speed Operational Amplifiers 2.5V 200MHz GBW CMOS Single Op Amp |
Data Sheet |
|
|
||||||||||||
